12

2013-08-27 #:125-9465-3 2013-10-11

5

Leaving ¼", thread two M10 x 15mm (N) screws through plate assembly (M) and rotating plate.

ENG

M

N

Rotating Plate

ENG

6

Slide plate assembly (M) into adapter bracket (L) slots.

ENG

L

M
